PELLET STOVES Chapter 5

USE AND MAINTENANCE MANUAL

page 28

5. LCD REMOTE CONTROL

5.1. Characteristics of the remote control

The remote control operates at a transmission frequency of 434.5MHz.

Power the product with three AAA batteries as follows:

Remove the cover of the battery compartment by pressing and lifting it

as shown by the arrow

Insert the batteries according to the correct polarity (+) and (-)

Close the cover of the battery compartment

When power is supplied to the remote control the time setting will

automatically be prompted (see paragraph 5.4.1).

The remote control tells the user when the batteries are about the run

out via the relevant icon on the display. If the flat battery icon appears,

this means that the batteries are almost flat and the remote control is

about to switch off.

5.2. Graphic appearance

In the instructions herein, we will often refer to the indications of the

buttons shown in the figure. For simplicity, always keep the figure to

hand.

Used batteries contain metals that are harmful to the

environment. Therefore, they must be disposed of

separately in suitable containers.

D D
